Tracetape® Detectable Marking Tape
Marking tape featuring an integral tracer wire provides visual identification and reliable detection of buried utilities.
Tracetape® combines embedded tracer wire with two layers of woven polyethylene film for reliable utility identification. The integrated tracer wire provides detection capability while the durable construction ensures long-lasting performance underground.
Embedded tracer wire provides reliable detection capability while woven film resists the deterioration common in traditional foil-based detectable tapes.
Underground utility damages are still common and often preventable. These statistics from the 2024 DIRT Report & Public Dashboard underscore the need for improved locating practices.
Each material is carefully selected for its ability to deliver long-lasting identification for underground utilities.
Open Trench
Film: 5 mil
Core: 3,000 lbf. (ASTM D6775)
31,500+ PSI (ASTM D882)
500 feet
Excellent resistance to acids.
Good resistance to alkalis.
Not attracted by mildew.
Excellent resistance to aging.
Supporting documents for the evaluation of Tracetape® Detectable Marking Tape. Contact us for additional information or guidance.
Proper installation of detectable marking tape ensures optimal location for underground utilities. See the installation sheet for step-by-step instructions.
Third-party test report for ASTM D882-18 Tensile Properties of Thin Plastic Sheeting. This test was conducted by National Technical Systems (NTS).
Quick reference guide to our core underground warning and marking tape products, including specifications and customization options.
Choose the right configuration for your project. Customizable options are available to match your utility type and identification requirements.
Red is used to serve as a warning for the presence of electric power lines, cables, and conduit.
Orange is used to indicate the presence of telecommunication lines, alarm or signal lines, cables, and conduit.
Yellow is used to warn of underground gas, oil, steam, petroleum, and other gaseous materials.
Green is used to indicate the location of sewers and drain lines.
Blue is used to indicate the presence of drinking water lines (clean, potable water).
Purple is most often used for reclaimed water but is also used to indicate user-defined utilities such as irrigation lines.
4"
Recommended for small-diameter utilities up to four inches wide, such as service laterals, conduit, and residential distribution lines.
6"
Recommended for utilities between four to six inches wide, including mid-size distribution lines and fiber ducts.
12"
Recommended for utilities wider than six inches, including larger mains or multiple parallel runs.
14 AWG CCS Tracer Wire
The most popular detectable option for Tracetape®, offers a reliable balance of signal strength, flexibility, and cost for standard detection needs.
12 AWG CCS Tracer Wire
Provides higher conductivity and added durability for longer runs or applications requiring stronger signal transmission.
Standard Legends
Standard legends are available with commonly used utility-specific warning language. Legends are available for: Water, Sewer, Reclaimed Water, Electric, Fiber, and Gas.
Customizable Legends
The digital printing process accommodates custom warning messages and full color-logos. This option is often selected to include an emergency contact number.
If you're ready to upgrade your marking system, tell us about your next project. A member of our sales team will reach out shortly.
